產品參數
| 產品型號 | 額定功率 | 額定力矩 | 額定轉速 | 額定電流 | 峰值扭矩 | 峰值電流 | 最大轉速 |
| (Kw) | (Nm) | (rpm) | (Arms) | (Nm) | (Arms) | (rpm) | |
| 40度環境溫度220VAC | |||||||
| EX310EAP | 0.4 | 1.66 | 2300 | 1.2 | 4.2 | 3.6 | 2300 |
| EX310EAK | 0.64 | 1.54 | 4000 | 2 | 4.2 | 0. | 4000 |
| EX420EAP | 0.77 | 3.18 | 2300 | 2.3 | 8.3 | 6.2 | 2300 |
| EX420EAJ | 1.12 | 2.67 | 4000 | 3.3 | 8.3 | 10.7 | 4000 |
| EX430EAL | 1.02 | 4.2 | 2300 | 3 | 11.5 | 8.3 | 2300 |
| EX430EAF | 1.37 | 3.3 | 4000 | 4.1 | 11.5 | 14.5 | 4000 |
| EX620EAV | 0.76 | 6.6 | 1100 | 2.4 | 16.7 | 6 | 1100 |
| EX620EAR | 1.33 | 5.8 | 2200 | 4 | 16.7 | 11.2 | 2200 |
| EX630EAR | 1.43 | 9.4 | 1450 | 4.2 | 25.9 | 11.5 | 1450 |
| EX630EAN | 2.02 | 8.4 | 2300 | 5.7 | 25.9 | 17.3 | 2300 |
| EX820EAR | 2.57 | 11.2 | 2200 | 7.5 | 32.5 | 23.2 | 2200 |
| EX840EAK | 3.31 | 15.8 | 2000 | 9.4 | 58.2 | 35.6 | 2000 |
| EX860EAJ | 3.86 | 25.4 | 1450 | 11.5 | 83.3 | 39.2 | 1450 |
| 40度環境溫度380VAC | |||||||
| EX310EAP | 0.64 | 1.54 | 4000 | 1.1 | 6.6 | 3.1 | 4000 |
| EX310EAK | 0.87 | 1.23 | 6800 | 1.6 | 6.6 | 5.4 | 6800 |
| EX420EAP | 0.94 | 3 | 3000 | 2.1 | 8.3 | 6.2 | 3000 |
| EX420EAJ | 1.11 | 1.8 | 6000 | 2.3 | 8.3 | 10.7 | 6000 |
| EX430EAL | 1.37 | 3.3 | 4000 | 2.3 | 11.5 | 8.3 | 4000 |
| EX430EAF | 1.37 | 3.3 | 4000 | 4.1 | 11.5 | 14.5 | 5800 |
| EX620EAV | 1.25 | 6 | 2000 | 2.2 | 16.7 | 6 | 2000 |
| EX620EAR | 1.53 | 3.8 | 3900 | 2.7 | 16.7 | 11.2 | 3900 |
| EX630EAR | 2.19 | 7.8 | 2700 | 3.5 | 25.9 | 11.5 | 2700 |
| EX630EAN | 2.18 | 5.2 | 4000 | 3.8 | 25.9 | 17.3 | 4000 |
| EX820EAR | 2.84 | 7.5 | 3600 | 5.2 | 32.5 | 23.2 | 3900 |
| EX840EAK | 0.99 | 2.9 | 3300 | 2.1 | 58.2 | 35.6 | 3500 |
| EX860EAJ | 2.35 | 9 | 2500 | 4.4 | 83.3 | 39.2 | 2600 |
